No-lube design: Ideal for high-purity applications where lubricants are not permitted.
Adjustable screw and lock nut : Allows for easy conversion of varying upstream pressure into accurate pre-set downstream pressure
Isolated stainless steel spring : Prevents metal contact with the fluid, making it suitable for harsh chemicals, DI water, and other high-purity applications.
Top entry and parallel inlet/outlet ports: Facilitates installation and avoids piping problems.
Wide material compatibility : Available in PVC, Polypropylene, PVDF, and Teflon for the valve body, and EPDM, Viton, and Kalrez for seals.
During assembly, a small amount of DuPont Krytox is applied to
assist in the break-in of moving parts, then carefully wiped off.
Test data was performed with 68°F water and a maximum pressure of 160 PSIG.
The performance curves will change with higher viscosity liquid and/or higher temperatures.
Metrail
Temperature
OTHER
0°F-340°F
POLYPRO
0°F-180°F
PVC
0°F-140°F
PVDF
0°F-280°F
TEFLON
0°F-340°F
¼” to 1” Valve FNPT
All valves are fully ported
1.5” to 3” Valve MPT
